Wide-belt sander Maxx 4 1300

Original construction of the series Maxx 4 has been developed for customers who require simplicity, reliability and quality for all technologies of sanding. Metal sanding is very easy task for this machine.

Maxx 4 excels in its robustness, reliability and variable combination of sanding units. Main advantage of wide belt sanders Maxx is satisfaction and reliability of thousands of customers proven worldwide.

I am interested in this machine

Show 3D Model

Machine benefits

2011
We produce the machine since 2011

11
We delivered the machine to 11 of the world's countries

60
We produced the machine for 60 of satisfied customers

combines 3 different types of working units (drum brush B, disc brush D, grinding roller R)

sanding belt length is 1900 mm - optional 2200 mm

working rolls diameter is 120 mm

workpiece thickness 0,5 - 160 mm

sand up to 1300 mm wide material

11 - 15 kW for unit R, 11 kW for unit B, 2,2 kW for unit D

Use

Wide belt sanders Maxx 6W series are designed for sanding (machining) workpieces from metal.

Interesting product

Universal machine with variety of working units, proved robust contruction.

Specifications

Sanding belt width	1 330 mm
Sanding belt length	1 900 mm
Table stroke	220 mm
Shaft diameter	60 mm

3D Model

Standard equipment

rubbered roller D=120 mm, 60 Sh
sanding belt speed 18 m/s
sanding belt dimensions 430x1900 mm, 830x1900 mm, 1120x1900 mm, 1330x1900 mm
motorized table height adjustment
min./max. workpiece height 0,5/160 mm
automatic star/delta switch
feed belt motor frequency inverter- speed 2-10 m/min
ammeter for motor of sanding unit
optical sensor control of abrasive belt oscillation
electronic measuring of table position with digital display
rubber pressure rollers with covered quides
main motor pneumatic disc brake
pressure switch 3,5-4,0 bar
sanding belt
CE certification

Optional accessories
